An Outdoor 18 Port Switch With 16 Gigabit PoE-Out Ports And 2 SFP+. Power All Your Access Points Anywhere
Description
netPower 16P: The Ultimate Outdoor PoE Switch for Tower and Mast Installations
Powering multiple access points, IP cameras, and uplinks on a tower or mast has never been easier or more efficient. The netPower 16P outdoor PoE switch offers:
-
16 Gigabit Ethernet ports with PoE-out for reliable and fast connectivity
-
2 SFP+ ports for 10G fiber uplinks, ensuring high-speed data transfer
-
Compact and sturdy outdoor enclosure for mounting in various environments, including damp attics, shafts, towers, masts, and poles with hose clamps
With a non-blocking throughput of 36 Gbps, switching capacity of 72 Gbps, and forwarding rate of 53.6 Mpps, the netPower 16P is designed for demanding applications.
Important Notes:
-
The device requires a 24V PSU for 24V PoE out or 48V PSU for 48V PoE out (IEEE 802.3 at/af)
-
Power supply is not included, allowing you to choose your preferred option, such as a battery pack or compatible MikroTik power supplies (24HPOW, 48POW, and 48V2A96W)
Upgrade your outdoor network infrastructure with the netPower 16P, the ultimate PoE switch for tower and mast installations!
Keywords: netPower 16P, outdoor PoE switch, tower installation, mast installation, Gigabit Ethernet, SFP+ ports, PoE-out, 10G fiber uplinks, non-blocking throughput, switching capacity, forwarding rate.
Specifications
| Details | |
|---|---|
| Product code | CRS318-16P-2S+OUT |
| Architecture | ARM 32bit |
| CPU | 98DX226S |
| CPU core count | 1 |
| CPU nominal frequency | 800 MHz |
| Switch chip model | 98DX226S |
| Dimensions | 303 x 212 x 78 mm |
| RouterOS license | 5 |
| Operating System | RouterOS / SwitchOS |
| Size of RAM | 256 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 200’000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| Suggested price | $279.00 |
Powering
| Details | |
|---|---|
| Number of DC inputs | 2 (DC jack) |
| DC jack input Voltage | 18-30 V / 48-57 V |
| Max power consumption | 316 W |
| Max power consumption without attachments | 16 W |
| Cooling type | Passive |
PoE-out
| Details | |
|---|---|
| PoE-out ports | Ether1-Ether16 |
| PoE out | 802.3af/at |
| Max out per port output (input 18-30 V) | 1.1 A |
| Max out per port output (input 30-57 V) | 0.6 A |
| Max total out (A) | 2.8A (18V-30V) & 1.4A (48V-57V) x2 |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 16 |
| Number of 1G Ethernet ports with PoE-out | 16 |
Fiber
| Details | |
|---|---|
| SFP+ ports | 2 |
Other
| Details | |
|---|---|
| CPU temperature monitor | Yes |
| Voltage Monitor | Yes |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | IP54 |
